TERRAIN MICRO BESPOKE P40
The Ledeire Terrain Micro P40 is a robust bespoke luminaire designed for precision outdoor and architectural lighting. Featuring a CREE XPE LED source with 1W, 2W, or 3W options, it provides color temperatures from 2700K to 6000K, including red, green, and blue, with Ra>80 color rendering and 100 lm/W efficiency.
Built with anodised aluminum housing, AISI316 trim, and tempered glass capable of 500kg load, the P40 ensures exceptional durability and protection, including IP67 ingress and IK09 impact resistance. Its optics range from 6° to 60°, offering versatile beam control, while dimming is supported via Switching, DALI, or 1–10V systems.
Operating on DC12–24V (Class III), the P40 delivers reliable performance in temperatures from –40°C to +50°C, with a 50,000-hour LED lifespan. Supplied without a power drive, it includes a 0.5m H05RN-F 2×1.0mm² cable and IP67-rated nickel-coated copper or stainless steel gland, suitable for ground or ceiling installations.
- AISI316 trim with tempered glass (500kg loading)
- anodised aluminum housing
- can be customized to R/G/B/Y color requirements
- supplied without power drive

Technical Specification
type
125497500
code
GR316. __ . __
built
marine grade SS316 / tempered glass
input volt
DC12-24V (class III)
source
LED 1/2/3W CREE XPE
efficiency
100lm/W
color temp
2700K/3000K/4000K/6000K/R/G/B
color rendering
Ra>80
optics
6°/11°/17°/23°/45°/60°
dimming
switching/ DALI/ 1-10v
installation
ground/ceiling
ingress
IP67
impact
IK09
weight
0.23kg
operating temp
-40°c – +50°c
LED life
50,000hrs
cable
0.5M H05RN-F2x1.0mm2
cable gland
IP67 nickel coated copper / SS AISI 316


Ordering Code Key
model
power
CCT
optics
dim
finish
P40
1
2
3
27
30
40
60
R
G
B
6
11
17
23
45
60
S
10V
DA
GRY
